6.20mm Pitch Wire To Board Connectors series product

6.20mm Pitch Wire To Board ConnectorsZOOKE6200 SPECIFICATIONS Current rating：20A AC/DC Voltage rating：300V AC/DC Withstanding voltage：1500V AC/miuute. Contact resistance：20MΩ Max. Insulation resistance：1000MΩ Min. Temperature range：-40℃~+105℃ Wire range：AWG 16#~20#   Item Material Pin QTY Housing PA66 UL94V-0 01~04 500Pcs/Bag Wafer - - - Terminal Phosphor Bronze - 3000Pcs/Reel   Wire to board connectors with a 6.20mm pitch have become increasingly popular in the electronics industry due to their compact size and high reliability. A wire to board connector is a type of electrical connector that allows for the connection of wires to a printed circuit board (PCB). These connectors are commonly used in applications where a durable and secure connection between wires and the PCB is required.   The 6.20mm pitch refers to the distance between each pin or contact in the connector. A smaller pitch allows for more contacts to be packed into a…
