Electrical Data MCX Temperature Range -55 °C ~ +155 °C (PE Cable -40 °C ~ +105 °C) Impedance 50Ω, 75Ω Frequency range DC-6 GHz Working voltage 250V (50Ω), 170V (75Ω) at sea level Withstanding Voltage 500V (50Ω), 250V (75Ω) at sea level Contact resistance   Center contact ≤5mΩ Outer contact ≤2.5mΩ Insulation resistance ≥1000mΩ Center conductor retention force ≥0.28N Coupling nut retention force  …
