Horizontal Machining Center SPECIFICATION UNIT HMC500D HMC630D HMC800D X-axis travel mm 740 1050 1300 Y-axis travel mm 680 750 1000 Z-axis travel mm 650 900 1000 B-axis servo motor torque (FANUC) bis12 bis22 bis22 Table size mm 500×600 630×700 800×800 Table indexing 1°×360 1°×360 1°×360 T-slots (No./width/pitch) 5-18-100 5-18-100 6-22-125 Table rotation speed rpm 16.6 11.1 11.1 Loading capacity kg 600 950 1500 Locking force (35kg /cm2) kg/m 5000 5000 5000 Distance spindle center to table mm 120-800 120-870 120-1120 Distance spindle nose to table center mm 130-780 130-1030 200-1200 Spindle taper BT-40 BT-50 BT-50 Spindle speed rom 8000 6000 6000 Main motor power kw 11/15 15/18.5 15…
