10-layer 3+N+3 HDI PCB

10-layer 3+N+3 HDI PCB Name: 10-layer 3-stage HDI PCB Layers: 3+N+3 Sheet: FR4 Tg170 Plate thickness: 1.2mm Panel size: 126*118mm/4 Outer copper thickness: 35μm Inner layer copper thickness: 18μm Minimum through hole: 0.20mm Minimum blind hole: 0.10mm Minimum BGA: 0.25mm Line width and spacing: 2.8/3.2mil Product Details Technical Features and Applications of HDI PCBs Impedance Specifications · 50 Ω Antenna · 90Ω & 100Ω Differential Impedance Applications Consumer Electronics · Cell Phones · Tablets · Ultrabooks · E-Readers · MP3 Players · GPS · Portable Game Consoles · DSCs (Digital Still Cameras) · Cameras · LCD TVs · POS Terminals High-Density Interconnect (HDI) PCB Usage Mobile and Portable Devices HDI PCBs are widely used to reduce the weight and overall size of products, as well as improve the elec…
